| MSD Shear Model | Excvator Weight 2nd Member (LBS) | Excvator Weight 3rd Member (LBS) | MSD Weight (LBS) | Jaw Opening (IN) | Jaw Depth (IN) | Reach (2nd Member) (FT) |
| MSD 7R | 7,500 | 15,000 | 1,100 | 10" | 11" | 5' |
| MSD 800 | 15,000 | 20,000 | 2,735 | 15" | 17" | 7'3" |
| MSD 800R | 18,000 | 26,000 | 2,250 | 15" | 17" | 7'3" |
| MSD 1000 | 20,000 | 35,000 | 4,200 | 19" | 20" | 5'11" |
| MSD 1000R | 23,000 | 40,000 | 4,400 | 19" | 20" | 8'6" |
| MSD 1500 | 27,000 | 55,000 | 6,600 | 22" | 25" | 6'9" |
| MSD 1500R | 40,000 | 66,000 | 7,000 | 22" | 25" | 9'3" |
| MSD 2000 | 42,000 | 70,000 | 8,850 | 28" | 29" | 8'3" |
| MSD 2000R | 50,000 | 90,000 | 10,200 | 28" | 29" | 11'0" |
| MSD 2250 | 44,000 | 88,000 | 10,500 | 30" | 30" | 8'0" |
| MSD 2250R | 55,000 | 110,000 | 12,500 | 30" | 30" | 11'9" |
| MSD 2500 | 50,000 | 90,000 | 12,000 | 32" | 34" | 8'9" |
| MSD 2500R | 70,000 | 110,000 | 14,600 | 32" | 34" | 12'6" |
| MSD 3000 | 70,000 | 144,000 | 13,300 | 35" | 38" | 9'10" |
| MSD 3000R | 95,000 | 160,000 | 17,000 | 35" | 38" | 14'1" |
| MSD 4000 | 80,000 | 150,000 | 16,600 | 40" | 44" | 12'0" |
| MSD 4000R | 100,000 | 170,000 | 19,000 | 40" | 44" | 14'11" |
| MSD 4500 | 90,000 | 160,000 | 17,900 | 38" | 43" | 10'8" |
| MSD 4500R | 110,000 | 185,000 | 21,000 | 38" | 43" | 14'2" |
| MSD 7500 | 135,000 | consult factory | 25,500 | 43" | 45" | 11'10" |
| MSD 7500R | 160,000 | 275,000 | 30,000 | 43" | 45" | 15'7" |
| MSD 9500 | 175,000 | consult factory | 37,300 | 48" | 52" | 15'4" |
| MSD 9500R | 275,000 | consult factory | 43,300 | 48" | 52" | 18'4" |
